Technical Specifications

General

Sample Rates44.1, 48, 88.2, 96, 176.4, or 192 kHz

Converter Resolution24 bit

ADC Converter Dynamic Range108 dB

DAC Converter Dynamic Range108 dB

Microphone Inputs

Maximum Level+10 dBu (±0.5 dBu, min gain)

Gain Range50 dB

Frequency Response20 Hz - 20 kHz (±0.3 dBu, unity gain, unwtd)

Dynamic Range106 dB (A-wtd, min gain)

THD + N0.004% (1 kHz, -1 dBFS, min gain)

EIN-126 dBu (A-weighted, 150Ω, max gain)

Input Impedance1.4 kΩ

Phantom Power+48 VDC (10 mA total)

Instrument Inputs

Maximum Level+19 dBu (min gain)

Gain Range50 dB

Frequency Response20 Hz – 20 kHz (±0.1 dBu, unity gain, unwtd)

Dynamic Range105 dB (A-wtd, unity gain)

THD + N0.002% (1 kHz, min gain)

Input Impedance750 kΩ

Main Outputs

Type

¼" TRS, Female

Maximum Level+10 dBu (1 kHz, unity gain, balanced)

Frequency Response20 Hz – 20 kHz (±0.3 dBu, unity gain, unwtd)

Dynamic Range104 dB (unity gain, unwtd)

THD + N0.001% ( 1 kHz, -1 dBFS, unity gain)

Headphone Outputs

Maximum Power47 mW / channel @ 56Ω

Frequency Response20 Hz – 20 kHz (±0.5 dBu, unity gain, unwtd)

Dynamic Range83 dB (A-wtd, 56Ω load)

THD + N0.01% (1 kHz, 0 dBFS, loaded)

Impedance Working Range32Ω to 300Ω

Physical

Height1.75" (44 mm)

Width7" (180 mm)

Depth5.5" (144 mm)

Weight2 lbs. (0.9 kg)
